BRAHMA F4 (FC) Highlights:

Reliable & Efficient Flight Processor

Powered by the STM32F405 MCU, the BRAHMA F4 delivers stable, responsive performance ideal for FPV drones, medium-lift builds, and multirotors requiring dependable control.

Precision Flight Sensors

Equipped with a BMI270 6-axis gyro and DPS310 barometer, ensuring smooth stabilization and accurate altitude performance.

Expanded Connectivity

Features 4 UART ports, I2C support, SBUS, RSSI, and a Type-C USB port, enabling easy integration with GPS, receivers, VTX systems, and more.

Supports 8 Motors

ESC signal pads M1–M8 are available, suitable for quad, hex, and X8-style builds.

Multiple BEC Outputs

• 5V (2A total across 7 groups)
• 9V (2A)
• 4.5V (from USB for receiver power)
• 3.3V (500mA)
  Perfect for powering cameras, LEDs, GPS, receivers, and accessories.

Built-In Blackbox Storage

Comes with a 32MB Winbond Blackbox, enabling detailed tuning and flight log analysis.

Enhanced Protection & Compatibility

Includes reverse polarity protection, USB ESD protection, and full support for Betaflight, iNav, and Ardupilot firmware.

LED & DJI Compatibility

• Supports Betaflight LED strip pads
• DJI Air Unit direct soldering supported for digital FPV builds

Mounting

Standard 30.5 × 30.5mm (M4) stack mounting for universal frame compatibility.

Proudly Made in India

Built with high quality and reliability, showcasing India’s rapidly advancing drone engineering.

VISHNU 60 (ESC) Highlights:

High-Performance 60A ESC

Supports 60A continuous and 90A burst, designed for high-thrust builds, 5"–10" drones, and heavy-duty aerial platforms.

BLHeli_S / BlueJay Firmware (JH_50)

Ensures smooth motor response, clean throttle control, and reliable handling.

3–6S LiPo Input

Compatible with a wide range of drone setups and power requirements.

DSHOT300/600 Support

Fast, digital ESC protocol for stable, responsive control.

Inbuilt Current Sensor

Provides real-time power draw data for tuning, filtration, and flight safety.

Robust Build

• Standard 30.5×30.5mm (M4) mounting
• Copper-rich PCB for heat distribution
• 14g lightweight yet durable design

Trusted Made-in-India Quality

Designed and manufactured for reliability, longevity, and high performance.
